Defines information for the camera module.
A camera module is a physical grouping of a serializer, image sensor(s), and associated EEPROM(s).
Definition at line 240 of file NvSIPLDeviceBlockInfo.hpp.
Data Fields | |
| std::string | name = "" |
| Holds the name of the camera module, for example, "SF3324". More... | |
| std::string | description = "" |
| Holds the description of the camera module. More... | |
| uint32_t | linkIndex {UINT32_MAX} |
| Holds the index of the deserializer link to which this module is connected. More... | |
| SerInfo | serInfo |
| Holds the SerInfo of the serializer. More... | |
| bool | isEEPROMSupported {false} |
| Holds EEPROM support. More... | |
| EEPROMInfo | eepromInfo |
| Holds the information about EEPROM device in a camera module. More... | |
| SensorInfo | sensorInfo |
| Holds the information about the sensor in a camera module. More... | |
| std::string nvsipl::CameraModuleInfo::description = "" |
Holds the description of the camera module.
Definition at line 246 of file NvSIPLDeviceBlockInfo.hpp.
| EEPROMInfo nvsipl::CameraModuleInfo::eepromInfo |
Holds the information about EEPROM device in a camera module.
Definition at line 257 of file NvSIPLDeviceBlockInfo.hpp.
| bool nvsipl::CameraModuleInfo::isEEPROMSupported {false} |
Holds EEPROM support.
Definition at line 254 of file NvSIPLDeviceBlockInfo.hpp.
| uint32_t nvsipl::CameraModuleInfo::linkIndex {UINT32_MAX} |
Holds the index of the deserializer link to which this module is connected.
Definition at line 250 of file NvSIPLDeviceBlockInfo.hpp.
| std::string nvsipl::CameraModuleInfo::name = "" |
Holds the name of the camera module, for example, "SF3324".
Definition at line 243 of file NvSIPLDeviceBlockInfo.hpp.
| SensorInfo nvsipl::CameraModuleInfo::sensorInfo |
Holds the information about the sensor in a camera module.
Definition at line 259 of file NvSIPLDeviceBlockInfo.hpp.
| SerInfo nvsipl::CameraModuleInfo::serInfo |
Holds the SerInfo of the serializer.
Definition at line 252 of file NvSIPLDeviceBlockInfo.hpp.
