Definition at line 549 of file nvmedia_parser.h.
Data Fields | |
| pfnCbNvMediaBeginSequence | BeginSequence |
| callback to provide sequence level information to client Client will use this to create NvMediaIDE based on codec type. More... | |
| pfnCbNvMediaDecodePicture | DecodePicture |
| callback to provide one frame/field worth of data required to achieve decoding using NvMediaIDE component. More... | |
| pfnCbNvMediaDisplayPicture | DisplayPicture |
| Callback to pass frame-buffer with its timestamp in display order for display. More... | |
| pfnCbNvMediaUnhandledNALU | UnhandledNALU |
| Callback to report unhandled NALU. More... | |
| pfnCbNvMediaAllocPictureBuffer | AllocPictureBuffer |
| callback to get one free frame-buffer to do current frame decoding. More... | |
| pfnCbNvMediaRelease | Release |
| Callback to tell client to decrement the buffer reference count by 1. More... | |
| pfnCbNvMediaAddRef | AddRef |
| Callback to increase ref counting of buffer by 1 when surface is used as reference. More... | |
| pfnCbNvMediaCreateDecrypter | CreateDecrypter |
| Callback to create NvMediaVideoDecrypter component to handle encrypted contents. More... | |
| pfnCbNvMediaDecryptHdr | DecryptHdr |
| Callback to pass encrypted data for decryption of frame-headers. More... | |
| pfnCbNvMediaSliceDecode | SliceDecode |
| Callback to pass slice level data for the slice level decoding use case. More... | |
| pfnCbNvMediaGetClearHdr | GetClearHdr |
| callback to get clear header data from NvMediaVideoDecrypter. More... | |
| pfnCbNvMediaGetBackwardUpdates | GetBackwardUpdates |
| callback to get backward prabability data for VP9 codec. More... | |
| pfnCbNvMediaGetDpbInfoForMetadata | GetDpbInfoForMetadata |
| callback to pass internal DPB information to the client. More... | |
| pfnCbNvMediaAddRef NvMediaParserClientCb::AddRef |
Callback to increase ref counting of buffer by 1 when surface is used as reference.
Definition at line 580 of file nvmedia_parser.h.
| pfnCbNvMediaAllocPictureBuffer NvMediaParserClientCb::AllocPictureBuffer |
callback to get one free frame-buffer to do current frame decoding.
Increase the ref counting of buffer by 1
Definition at line 572 of file nvmedia_parser.h.
| pfnCbNvMediaBeginSequence NvMediaParserClientCb::BeginSequence |
callback to provide sequence level information to client Client will use this to create NvMediaIDE based on codec type.
Client will use NvMediaIDECreate based on need. Clients use codec sequence information to create output buffers required for decoding.
Definition at line 557 of file nvmedia_parser.h.
| pfnCbNvMediaCreateDecrypter NvMediaParserClientCb::CreateDecrypter |
Callback to create NvMediaVideoDecrypter component to handle encrypted contents.
Definition at line 582 of file nvmedia_parser.h.
| pfnCbNvMediaDecodePicture NvMediaParserClientCb::DecodePicture |
callback to provide one frame/field worth of data required to achieve decoding using NvMediaIDE component.
Client will get NvMediaParserPictureData information. It will have to just update target surface pointer with a reference to an NvSciBufObj where the frame needs to be rendered. Client will call NvMediaIDERender based on use case requirement.
Definition at line 565 of file nvmedia_parser.h.
| pfnCbNvMediaDecryptHdr NvMediaParserClientCb::DecryptHdr |
Callback to pass encrypted data for decryption of frame-headers.
Definition at line 584 of file nvmedia_parser.h.
| pfnCbNvMediaDisplayPicture NvMediaParserClientCb::DisplayPicture |
Callback to pass frame-buffer with its timestamp in display order for display.
Definition at line 567 of file nvmedia_parser.h.
| pfnCbNvMediaGetBackwardUpdates NvMediaParserClientCb::GetBackwardUpdates |
callback to get backward prabability data for VP9 codec.
Client will call NvMediaIDEGetBackwardUpdates inside this callback to fill the NvMediaVP9BackwardUpdates structure
Definition at line 597 of file nvmedia_parser.h.
| pfnCbNvMediaGetClearHdr NvMediaParserClientCb::GetClearHdr |
callback to get clear header data from NvMediaVideoDecrypter.
This is called after DecryptHdr callback to get frame-headers data.
Definition at line 592 of file nvmedia_parser.h.
| pfnCbNvMediaGetDpbInfoForMetadata NvMediaParserClientCb::GetDpbInfoForMetadata |
callback to pass internal DPB information to the client.
Some clients need DPB information to support error-resilience in the encoder. This callback supports conferencing use cases.
Definition at line 602 of file nvmedia_parser.h.
| pfnCbNvMediaRelease NvMediaParserClientCb::Release |
Callback to tell client to decrement the buffer reference count by 1.
When the reference count reaches 0, the buffer can be used for further for decoding
Definition at line 576 of file nvmedia_parser.h.
| pfnCbNvMediaSliceDecode NvMediaParserClientCb::SliceDecode |
Callback to pass slice level data for the slice level decoding use case.
Client will call NvMediaIDESliceDecode() to pass the information for slice level decoding
Definition at line 588 of file nvmedia_parser.h.
| pfnCbNvMediaUnhandledNALU NvMediaParserClientCb::UnhandledNALU |
Callback to report unhandled NALU.
Definition at line 569 of file nvmedia_parser.h.
